Road Roller XCMG XS143J
Road Roller XCMG XS143J
The XCMG XS143J road roller is a reliable and high-performance machine designed for compacting various types of bases and asphalt surfaces during the construction of roads, airports, dams, and other infrastructure projects. The XS143J model is equipped with a powerful and fuel-efficient engine, ensuring stable operation even in challenging conditions. One of its main advantages is its high weight and optimal weight distribution, which guarantees excellent compaction quality.
The roller features a simple and reliable design, easy operation, and enhanced maneuverability. Thanks to its single-frequency vibration system with a large amplitude, it effectively compacts both granular and cohesive soils.
Key Specifications of XCMG XS143J:
Operating weight: approximately 14,000 kg
Rated engine power: 102–118 kW
Drum width: approximately 2130 mm
Static linear load: high, ensuring effective compaction
Vibration type: single-drum vibratory
The XCMG XS143J combines reliability, performance, and affordability, making it an excellent choice for companies engaged in road construction.
Technical Specifications
Length, mm
6150
Width, mm
2340
Height, mm
3200
Engine model
SC4H140.1G2
Engine type
Diesel
Number of cylinders
4
Max. torque, Nm/rpm
1800
Operating weight, kg
14000
Engine power, hp
140
Fuel tank capacity, L
250
Engine displacement, cm³
12000
Number of forward gears
3
Number of reverse gears
2
Engine emission standard
Water-cooled
Roller diameter, mm
1523
Rated vibration amplitude, mm
1.9/0.95
Vibration force, kN
274/137
Vibration frequency, Hz
28
Drum width, mm
2124
Maximum speed, km/h
11
